Specifications: Working length 1025 mm
Max. working diameter 530 mm
Spindle speeds 38 - 3.800 rpm
Spindle bore 80 mm
Spindle speeds on the Sub spindle 5.000 rpm
Spindle bore 62 mm
Number of tools 44 - 12 pcs
No. of rotating stations 44 - 12 pcs
Spindle speeds rotating tools 200 - 6.000 rpm
Spindle taper Capto C 6 / VDI 40
X-axis travel 475 mm
Z Travel 1170 mm
Y-axis travel 160 mm
Control OSP - E 100 L
Cycle hours 26.000 Timer
Equipped with: 3 jaw chuck
Subspindel
Internal cooling
Rest
Full c axe
Subspindel
Gantry Loader
Interface RS-232 C
Chip conveyor
High pressure coolant unit
Service tools etc.
